ATD OBD-28390 OBD2 16 Male Pin Car Diagnostic Code Scanner Tool Engine Fault Check Reader

ATD OBD-28390 OBD2 16 Male Pin Car Diagnostic Code Scanner Tool Engine Fault Check Reader

SKU:
OBD-28390
Write a Review
  • Reads and displays diagnostic fault codes
  • Engine management check features
  • Easy To Operate: Plug and play.
  • 16 PIN OBD Male
  • Compatible with All Vehicles with a OBD port.
This product is normally stocked. If the status changes to back-order, we will send it out as soon as it arrives back into stock.
Price: £29.99
Description
Easy to operate: Plug and play. No need any battery or charger, this OBD2 reader gets the power directly from your vehicle through the OBD2 Data Link Connector. Quickly discover machine error codes and clear SRS error codes.Even a beginner can use this device to read the error code, and find out what the problem is. Save your money and time.


Practical & powerful function: OBD2 code reader features built-in OBD2 DTC lookup library, help you to determine the cause of the engine light, read code, erase code, view freeze frame, I/M ready, vehicle information, data flow, real-time
curve, get vehicle speed information, calculate load value, engine coolant temperature, get engine speed. Convenient and practical.


Accurate & easy to read: Designed with a large clear LCD display screen, which is with white backlight and contrast adjustment for direct display test results, accurate and easy to read. Once the error code appears, it will disappear only if you correct it.


Compact & portableThe handheld and compact design OBDII code readers is portable, Makes it simple-to-use and easy to handle with an anti-skid surface while diagnosing. And the small size means that you will be able to store the tool without encountering any sort of hassle.




Powerful compatibility: Supports 9 protocols compatible with most 1996 US cars, 2000 European and Asian cars and newer OBD II & CAN vehicles, domestic or imported. Supports up to 6 languages: English, German, Dutch, Italian, French and Spanish.




Specifications:
Colour: yellow
Working voltage: DC 9~16V
Working current: 80mA
Sleep current: no sleep mode
DC circuit: built-in
OBD interface: 16 PIN OBD male
LCD type: FSTN / semi-transparent reflective
Driver chip: ST7565 or C compatible IC
Backlight drive type: power / white
Settings: language, default units, contrast, help
Display: Badit, 128 * 64 pixels display
Working temperature: 0-60 ° C (32~140°F)
Storage temperature: -20~70°C (-4 ~158°F)
Storage temperature: -30~65 degrees
External power supply: car battery powered 8.0 to 15.0V
Software version: V310_FLASH_V01.01, V310_MCU_V06.01
Hardware version: V1.1
Dimensions: Length: 155mm Width: 85mm Height: 25mm Weight: 0.198Kg(0.431b)

Function:
1, diagnostic menu: read code, erase code, view freeze frame, I / M ready, vehicle information, data flow, real-time curve
2, real-time curve: vehicle speed, calculate the load value, engine coolant temperature, engine speed
3, system settings: language, unit of measure, contrast, help
4. DTC search: first range: P, C, B, U; second range: 0, 1, 2, 3; other range: 0 to F
5, support language: German, Italian, Dutch, Spanish, English, French

OBDII Supported Protocol:
1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2(5 baud init, 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
5. ISO14230-4 KWP (fast init, 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID, 500 Kbaud)
7. ISO15765-4 CAN (29bit ID, 500 Kbaud)
8. ISO15765-4 CAN (11bit ID, 250 Kbaud)
9. ISO15765-4 CAN (29bit ID, 250 Kbaud)

Vehicle coverage:
All Vehicles with a OBD port.

Package includes:
1x OBDII Code Reader
